RECT™ TS-5488MR8

RECT-ID:1748

RECT™ TS-5488MR8

RECT-ID: 1748
Ready for shipment in about 4-6 workdays
Express-shipping: start request...

Dual Intel Xeon Scalable R in a Tower Server

  • Aiming at making virtualization more comfortable than ever, Microsoft Windows Server 2019 with Hyper-V is easy to install and intuitive to manage. Lower the costs of your business by unleashing the full potential of your server with Hyper-V. Different processes that are crucial for your operations can be distributed to multiple virtual machines. This is a boost to the stability as these dedicated machines are running isolated from each other; therefore a server crash doesn't affect other running virtual machines. This way the in-firm efficiency can be raised considerably.

KeyFacts

  • equipped with the all new Intel® Xeon® Scalable R Processors with Cascade Lake SP microarchitecture
  • equipped with Intel Server chipset „Lewisburg“ (either Intel® C621 with 2x 1 Gbit-LAN or Intel® C622 with 2x 10 Gbit-LAN on board)
  • driven by two CPUs, scalable up to 28 Cores and 56 Threads, up to 3.80 GHz clock speed and 38.5 MB L3-Cache per CPU
  • scalable memory up to 1 TB DDR4-2933 (ECC Reg.)
  • scalable traditional storage with HDD and SSD up to 192 TB via S-ATA 6Gb/s or SAS 12Gb/s
  • scalable High Performance storage with Enterprise NVMe SSDs for up to 6 times higher transfer rates
  • featuring widespread Remote Management functions

Dual Intel Xeon Scalable R in a Tower Server

  • Aiming at making virtualization more comfortable than ever, Microsoft Windows Server 2019 with Hyper-V is easy to install and intuitive to manage. Lower the costs of your business by unleashing the full potential of your server with Hyper-V. Different processes that are crucial for your operations can be distributed to multiple virtual machines. This is a boost to the stability as these dedicated machines are running isolated from each other; therefore a server crash doesn't affect other running virtual machines. This way the in-firm efficiency can be raised considerably.

KeyFacts

  • equipped with the all new Intel® Xeon® Scalable R Processors with Cascade Lake SP microarchitecture
  • equipped with Intel Server chipset „Lewisburg“ (either Intel® C621 with 2x 1 Gbit-LAN or Intel® C622 with 2x 10 Gbit-LAN on board)
  • driven by two CPUs, scalable up to 28 Cores and 56 Threads, up to 3.80 GHz clock speed and 38.5 MB L3-Cache per CPU
  • scalable memory up to 1 TB DDR4-2933 (ECC Reg.)
  • scalable traditional storage with HDD and SSD up to 192 TB via S-ATA 6Gb/s or SAS 12Gb/s
  • scalable High Performance storage with Enterprise NVMe SSDs for up to 6 times higher transfer rates
  • featuring widespread Remote Management functions
Configuration
Basic configuration

Well priced: Please reset the configuration to have the basic configuration.

Recommended configuration

Choose the CORETOs recommended configuration.

Windows Server 2022
Loading...

Processor

  • Intel® Xeon® Scalable Bronze Processors
    Optimized performance for small businesses and basic storage Servers
    up max. 8 CPU Cores, 2133 MHz RAM speed
  • Intel® Xeon® Scalable Silver Processors
  • Intel® Xeon® Scalable Gold Processors
  • Intel® Xeon® Scalable Platinum Processors
  • Need more?   show more options
    Too much?   show less options

Memory

  • Need more?   show more options
    Too much?   show less options

Mainboard



Trusted Platform Module

Remote Management Interface on Board

IPMI 2.0, KVM over LAN, Virtual Media over LAN, Remote Power on/off and Reset, Remote Hardware Monitoring, Embedded Web-Server


Drives

8 in hot-swap trays, 2 internal (2.5")

    • Need more?   show more options
      Too much?   show less options
    • Need more?   show more options
      Too much?   show less options
    • Enterprise SSDs with optimized performance for read-intensive applications
    • Enterprise SSDs with optimized performance for read and write intensive applications (Mixed-Use)
    • Need more?   show more options
      Too much?   show less options
    • Enterprise SSDs with optimized performance for read-intensive applications
      (ERP, CRM, Data Warehouse, File Server, Database Analytics, Video Streaming)
    • Enterprise SSDs with optimized performance for read and write intensive applications (Mixed-Use)
      (Databases, OLTP, Financial Transactions, E-Commerce, E-Mail / Messaging, Virtual Environments)
    • Need more?   show more options
      Too much?   show less options

    2.5" SSDs, mounted internal, connected with the mainboard

    • SATA SSD
    • High performance data according to IOPS, lower TBW values. Optimized performance for read-intensive applications.
    • Excellent performance combined with very high endurance. Optimized performance for read and write intensive applications
    • U.2 NVMe SSD
    • High performance data according to IOPS, lower TBW values. Optimized performance for read-intensive applications.
    • Optimized performance for read and write intensive applications
    • Need more?   show more options
      Too much?   show less options
    • Disk on Module
      SATA DOMs (Disk On Module) are small flash modules that can be connected directly to the SATA port of the mainboard. They are perfectly suited for use as boot drives or OS installation devices.
    • M.2 NVMe SSD
      M.2 NVMe SSDs are very compact and fast plug-in cards that are connected via PCI-Express (up to 32 Gbit/s) on the motherboard. They are perfectly suited for use as boot drives or OS installation devices.
    • M.2 NVMe SSDs (PCIe 3.0)
    • Need more?   show more options
      Too much?   show less options

    Controller

    • Onboard controller
      Host-based solution with basic requirements - for price-optimized entry.

    • RAID-Controller
      Ideal for 12 Gbps performance-hungry systems demanding high I/O transaction and high bandwidth processing without compromising maximum data protection.




    • Need more?   show more options
      Too much?   show less options

    Controller Cache Protection

    Short-term data storage to protect data in RAID-Cache in case of power outage.

    RAID configuration



    NVMe SSD cards

    • Optimized performance for read and write intensive applications

    Network




















    • Copper patch cable (RJ-45), Cat.6A, 500MHz, halogen free
      Patch cable in the highest quality for a professional cabling in Gigabit and 10 Gigabit range (up to 100m).
      Cable sheath halogen free, full copper core, S/FTP (PiMf) 4x2xAWG26/7, gold plated contacts.
      For use in data centers and server racks

    Optical disc drive

    Power supply



    Tape Streamer (LTO)

    Streamers are generally special orders and therefore cannot be refunded within our money-back guarantee for new customers. Please ask our sales consultants for details.



    Streamer Cartridges

    Streamer Cartridges WORM

    LTO Ultrium WORM (Write Once, Read Many) media cartridges are available to meet today’s stringent regulatory and compliance requirements. Combined with native AES 256-bit encryption, WORM cartridges physically prevent data from being overwritten or tampered with, providing a reliable, accurate and scalable data integrity solution.

    Keyboard




    • Need more?   show more options
      Too much?   show less options

    Mouse


    Monitor


    Uninterruptible power supply (UPS)

    Protected from power interruptions?
    Choose from a wide variety  RECT Accessories - UPS

      Hot-Swap-Kit for SSDs (front)

      The Hot-Swap-Kit is perfect for use with system SSDs. It is connected to the S-ATA controller of the mainboard.


      Additional SSDs

      The additional SATA SSDs are mounted inside the hot-swap kit

      • High performance data according to IOPS, lower TBW values. Optimized performance for read-intensive applications.
      • Excellent performance combined with very high endurance. Optimized performance for read and write intensive applications
      • Need more?   show more options
        Too much?   show less options

      Microsoft Hyper-V pre-installation

      Installation of Microsoft Hyper-V usind the free license. Server Core Edition is being installed. You can manage Hyper-V Server by using Windows PowerShell locally or remotely, or by running Hyper-V Manager on a remote computer or server.

      Operating System

      The selected Microsoft operating system includes 30 days installation support, by phone or email.
      Further Microsoft editions plus Microsoft Open Licenses can be found under RECT Accessories. Further language editions on demand.

      language:


      • Microsoft Windows Server 2022




      • License Hints for Windows Server 2019/2022

        For correct licensing of the Standard Edition and Datacenter Edition with the chosen precessor equipment – - – a core license is required.
      • Need more?   show more options
        Too much?   show less options

      Additional Core Licenses for Windows Server 2022

      To license more cores than provided by the 16-core or 24-core base license.

      Microsoft Server Applications

      Each license covered by Software Assurance (SA) entitles you to upgrade to the latest version. Each active Server with Software Assurance allowss a passive-failover instance of the Server Application and an improved license mobility.





      Operating System CALs

      • Standard CALs for Device and/or User
        In addition to the server licenses, you need licenses for all clients accessing the server (Client Access Licenses). These CALs may be licensed by users (User CALs) or devices (Device CALs). A User CAL is recommended when a user accesses the server with different devices. A Device CAL is favourable when one device is used by different users to access the server. All CALs are downward compatible with earlier releases of Microsoft Server.
      • Remote Desktop Services CALs
        Required for the provision and use of Remote Desktop Services based on the number of users or devices accessing the service.


      • Microsoft SQL Server CALs




      • Microsoft Exchange Server CALs




      Backup - Software





      RECT Smart Warranty .HDD

      The best choice for sensitive data! With the RECT "Smart Warranty .HDD" you yourself can decide how you want to dispose of a faulty enterprise hard drive because you can simply keep that hard drive while we will take the necessary replacement directly to you.
      Note: ...The capacity and not the number of the inserted hard drives is decisive. In case you need hard drives with different capacities within one configuration, the chosen option for "Smart Warranty .HDD" has to comply with the biggest hard drive in it. For all details regarding the transaction, please see the service conditions for this service. SSDs are excluded from the RECT "Smart Warranty .HDD"

      • 36 months runtime for all 3.5" hard drives of the server
      • 60 months runtime for all 3.5" hard drives of the server

      Service & Support Level

      Location:

      • Bring-In Warranty
        Technical support: by e-mail, effective support with initial operation (to be carried out within 30 days after delivery).
        Rapairs: components or the whole system will be repaired or replaced subsequently to reshipment, we will pay the costs for transport and logistics within 30 days after delivery.
      • Pick-Up Warranty
        Technical support: by phone and e-mail, effective support with initial operation, installation and configuration (to be carried out within 30 days after delivery), support with software updates and patches (within the scope of current standard software, throughout the stipulated time period).
        Repairs: pick-up and return service for replacement of defective components or the whole system. Components will be replaced in the form of an advanced warranty replacement with guaranteed express delivery.
      • On-Site (3BD) Warranty
        Technical support: by phone and e-mail with prioritised handling directly after submission, effective support with initial operation, installation and configuration (to be carried out within 30 days after delivery), support with software updates and patches (within the scope of current standard software, throughout the stipulated time period).
        Repairs: on-site service with guaranteed reaction time within three business days for fault repair at the site of the system, optionally with advanced warranty replacement of defective components if handling can be speeded up that way.
      • On-Site (NBD) Warranty
        Technical support: by phone and e-mail with prioritised handling directly after submission, effective support with initial operation, installation and configuration (to be carried out within 30 days after delivery), support with software updates and patches (within the scope of current standard software, throughout the stipulated time period).
        Repairs: on-site service with guaranteed reaction time within the next business day for fault repair at the site of the system, optionally with advanced warranty replacement of defective components if handling can be speeded up that way.

      RECT™ TS-5488MR8

      Main configuration
      2,106.00
      Configuration:
      Complete Configuration
      Current price


      Main configuration: 2,106.00 €
      Complete Configuration: 0,00
      Current price: 0,00   (Plus VAT)
      RECT-ID: 1748
      Last update: 13.10.2024

      CORETO Aktiengesellschaft is a manufacturer of performance-specific servers and workstations.

      RECT™ is a product brand and the RECT™ store with configurator is a division of CORETO.
